Advantech's modular display series offers various display modules ranging between 12.1" and 23.8" inches in size to go with selections of computing boxes (TPC-B300/TPC-B510/ TPC-B520/TPC-B520L/TPC-B610) for multiple configurations that can be flexibly adapted to various scenarios. Modular display series are equipped with industrial grade LCD and Projected Capacitive touch screens, providing the best user experience and reliable operation. The modular design ensures flexible configuration and easy maintenance/upgrades. Its robust enclosure is equipped with a die-cast aluminum alloy front bezel and IP66 rating for protection from dust and water ingress.
- General Information
- Manufacturer
- Advantech Co., Ltd
- Manufacturer Website Address
- http://www.advantech.com
- Brand Name
- Advantech
- Product Type
- LED Touchscreen Monitor
- Technical Information
- Screen Size Class
- 15"
- Viewable Screen Size
- 15"
- Screen Mode
- XGA
- Panel Technology
- Thin Film Transistor (TFT)
- Aspect Ratio
- 4:3
- Horizontal Viewing Angle
- 160°
- Vertical Viewing Angle
- 150°
- Mount Type
- Panel Mount
- Backlight Technology
- LED
- Features
- Anti-glare
- Ingress Protection (IP) Rating
- IP66
- Video
- Maximum Resolution
- 1024 x 768
- Color Supported
- 16.2 Million Colors
- Native Contrast Ratio
- 800:1
- Brightness
- 1800 Nit
- Touchscreen Information
- Touchscreen Type
- Projected Capacitive
- Multi-touch Screen
- Yes
- Environmental Conditions
- Operating Temperature Range
- -4°F (-20°C) to 140°F (60°C)
- Physical Characteristics
- VESA Mount Compatible
- Yes
- Height
- 25.6 ft
- Width
- 31.9 ft
- Depth
- 27.5"
- Miscellaneous
- Package Contents
- FPM-D15T-HE Touchscreen LED Monitor
- 10 x CLAMPER
- 10 x CLAMPER Screw
- 1 x WARRANTY
