- General Information
- Manufacturer
- Cisco Systems, Inc
- Manufacturer Website Address
- http://www.cisco.com
- Brand Name
- Cisco
- Product Series
- 8500
- Product Type
- Wireless LAN Controller
The Cisco 8500 Series Controller provides centralized control, management, and troubleshooting for high-scale deployments in service provider and large campus deployments. The 8500 series provides flexibility to support multiple architectures in the same controller - centralized controller switched for campus, Cisco FlexConnect for lean branches managed over the WAN as well as mesh support for deployments where full Ethernet cabling is unavailable.
The Cisco 8500 Series Controller supports Application Visibility and Control (AVC). AVC includes the Network-Based Application Recognition 2 (NBAR-2) engine, Cisco's deep packet inspection (DPI) capability, which classifies applications, applies quality of service (QoS) settings to either drop or mark the traffic, and prioritizes business-critical applications in the network. AVC uses NetFlow Version 9 to export the flows. The Cisco 8500 Series controller also supports Bonjour Services Directory to enable Bonjour Services to be advertised and utilized in a separate Layer 3 network.
- Warranty
- Limited Warranty
- 90 Day
- Technical Information
- ISM Band
- No
- UNII Band
- No
- Wireless Security
- 3DES
- AES
- IKE
- SSL
- TLS 1.0
- TKIP
- WPA
- WPA2
- PKI
- AES-CCMP
- AES-CCM
- AES-CBC
- DTLS
- TLS 1.1
- Features
- Quality of Service (QoS)
- Interfaces/Ports
- Ethernet Technology
- 10 Gigabit Ethernet
- Ethernet
- Fast Ethernet
- Gigabit Ethernet
- Number of Network (RJ-45) Ports
- 1
- Network (RJ-11)
- No
- PoE (RJ-45) Port
- No
- VGA
- No
- HDMI
- No
- Audio Line Out
- No
- Serial Port
- No
- USB
- Yes
- Powerline
- No
- I/O Expansions
- Total Number of Expansion Slots
- 2
- Expansion Slot Type
- SFP+
- Number of SFP+ Slots
- 2
- Management & Protocols
- Management
- SNMP v1, v2c, v3
- Telnet
- MIB
- Syslog
- Web-based (HTTP/HTTPS)
- Cisco Wireless Control System (WCS)
- CLI
- RMON
- TFTP
- Power Description
- Input Voltage
- 110 V AC
- 220 V AC
- Physical Characteristics
- Form Factor
- Desktop
- Rack-mountable
- Height
- 1.7"
- Width
- 17.3"
- Depth
- 28"
- Weight (Approximate)
- 35.10 lb
- Miscellaneous
- Package Contents
- 8510 Wireless LAN Controller
- 0APs
- Dual AC PSU
- Certifications & Standards
- Safety:
- UL 60950-1:2003
- EN 60950:2000
- EMI and susceptibility (Class A)
- FCC Part 15.107 and 15.109
- ICES-003
- VCCI
- EN 55022
- EN 55024
- 802.3
- 802.3u
- 802.1Q
- 802.11b
- 802.11a
- 802.11d
- 802.11g
- 802.1x
- 802.11h
- 802.11e
- 802.11n
