The Cisco ME 3400E Series offers two different Cisco IOS® Software feature images. The METROACCESS image offers advanced quality of service (QoS), rate limiting, robust multicast control, and comprehensive security features. In addition, the METROACCESS image includes a rich set of Carrier Ethernet access features including 802.1Q Tunneling, Layer 2 Protocol Tunneling (L2PT), and Flexlink. The METROIPACCESS image adds advanced Layer 3 features such as support for advanced IP routing protocols, Multi-VPN Routing and Forwarding Customer Edge (Multi-VRF CE), and Policy Based Routing (PBR).
The SFP-based Gigabit Ethernet ports accommodate a wide range of 100BASE, 1000BASE, coarse wavelength-division multiplexing (CWDM), and dense wavelength-division multiplexing (DWDM) SFP transceivers. These ports also support the Cisco Catalyst® 3560 SFP Interconnect Cable for establishing a low-cost Gigabit Ethernet point-to-point connection.
- General Information
- Manufacturer
- Cisco Systems, Inc
- Manufacturer Website Address
- http://www.cisco.com
- Brand Name
- Cisco
- Product Series
- ME 3400E
- Product Condition
- Refurbished
- Product Type
- Layer 3 Switch
- Warranty
- Limited Warranty
- 90 Day
- Interfaces/Ports
- Total Number of Network Ports
- 24
- Token Ring Port
- No
- LRE Port
- No
- Uplink Port
- Yes
- Management Port
- Yes
- USB
- No
- Stack Port
- No
- Number of Network (RJ-45) Ports
- 26
- Port/Expansion Slot Details
- 24 x Fast Ethernet Network
- 2 x Gigabit Ethernet Network
- 2 x Gigabit Ethernet Expansion Slot
- Media & Performance
- Media Type Supported
- Twisted Pair
- Ethernet Technology
- Fast Ethernet
- Gigabit Ethernet
- Network Technology
- 10/100Base-TX
- 10/100/1000Base-T
- 1000Base-X
- I/O Expansions
- Total Number of Expansion Slots
- 2
- Expansion Slot Type
- SFP
- Shared SFP Slot
- Yes
- Number of SFP Slots
- 2
- Network & Communication
- Layer Supported
- 3
- Management & Protocols
- Manageable
- Yes
- Management
- CiscoWorks Support
- QoS
- VLAN
- SNMP v1, v2c, v3
- RMON 1, 2, 3, 9
- DHCP
- Telnet
- CLI
- HTTP
- Syslog
- Memory
- Standard Memory
- 128 MB
- Memory Technology
- DRAM
- Flash Memory
- 32 MB
- Reliability
- MTBF
- 245917 Hour
- Power Description
- PoE (RJ-45) Port
- No
- Power Source
- Power Supply
- Physical Characteristics
- Compatible Rack Unit
- 1U
- Form Factor
- Rack-mountable
- Desktop
- Height
- 1.8"
- Width
- 17.5"
- Depth
- 9.3"
- Weight (Approximate)
- 6.40 lb
- Miscellaneous
- Certifications & Standards
IEEE Standards:
- 802.1s
- 802.1w
- 802.1x
- 802.3ad
- 802.3ah
- 802.1ag
- 802.3x
- 802.1D
- 802.1p
- 802.1Q
- 802.3
- 802.3u
- 802.3ab
- 802.3z
EMC:
- FCC Part 15 Class A
- EN 55022 Class A (CISPR22 Class A)
- EN 55024
- EN 300 386
- GR-1089 CORE Issue 4
- GR-63 CORE Issue 3
- VCCI Class A
- AS/NZS 3548 Class A
- AS/NZS CISPR22 Class A
- KCC
- CE Marking
Safety:
- UL 60950-1, First Edition
- CUL to CAN/CSA 22.2 No.60950-1, First Edition
- TUV/GS to EN 60950-1
- NOM to NOM-019-SCFI (through distributors)
- CE Marking
- Country of Origin
- China
