- General Information
- Manufacturer
- QNAP Systems
- Manufacturer Website Address
- http://www.qnap.com
- Brand Name
- QNAP
- Product Type
- NAS Storage System
Unlock the potential of 6-bay storage capacity and harness the speed of 10GbE with the TS-632X! This versatile storage solution offers secure backup, rapid transmission, support for container applications, and much more. Cost-effective yet powerful, the TS-632X streamlines workflow efficiency without exceeding your budget.
Quad-core for multitasking
Quad-core 2.0GHz processor and 4 GB non-ECC RAM (expandable to 16 GB, supports ECC RAM)
Dual-port 10GbE SFP+
High-speed 10GbE connectivity enhances transfer speed for intensive data transmission and shortens backup time.
2.5GbE is a must!
Leverage SMB Multichannel or Port Trunking with built-in dual 2.5GbE ports to increase bandwidth and access speed.
PCIe Gen 3 expandability
Install a PCIe expansion card to add 2.5/5/10GbE connectivity or M.2 SSD slots to the NAS for more I/O potential.
Faster USB transfer and backup
Two USB 3.2 Gen 1 (5Gbps) ports with One Touch Copy support allow faster backup to/from USB devices.
Centralized backup and snapshot protection
Easily back up different types of data and endpoints and create snapshots regularly to prevent ransomware threats.
- Warranty
- Limited Warranty
- 2 Year
- Storage
- Number of Hard Drives Supported
- 6
- Number of Solid State Drive Installed
- 0
- Flash Memory Capacity
- 512 MB
- Processor & Chipset
- Processor Manufacturer
- Annapurna Labs
- Processor Type
- Alpine
- Processor Model
- AL524
- Processor Core
- Quad-core (4 Core)
- Processor Speed
- 2 GHz
- Memory
- Standard Memory
- 4 GB
- Memory Technology
- DDR4 SDRAM
- Network & Communication
- Ethernet Technology
- 2.5 Gigabit Ethernet
- I/O Expansions
- Number of Total Expansion Bays
- 6
- Number of 3.5" Bays
- 6
- Total Number of Expansion Slots
- 3
- Expansion Slot Type
- SFP+
- Controllers
- Controller Type
- Serial ATA/600
- RAID Supported
- Yes
- RAID Levels
- 0, 1, 5, 6, 10, 50, 60, Hot Spare, JBOD
- Interfaces/Ports
- Drive Interface
- Serial ATA/600
- Serial ATA/300
- HDMI
- Yes
- Total Number of USB Ports
- 4
- Number of USB 2.0 Ports
- 2
- Number of USB 3.2 Gen 1 Ports
- 2
- Network (RJ-45)
- Yes
- Number of Network (RJ-45) Ports
- 2
- Software
- Operating System
- QTS 5.2.3
- Management & Protocols
- Protocols
- IPv4
- IPv6
- SSH
- Telnet
- CIFS/SMB
- FTP
- AFP
- iSCSI
- SNMP
- SSL/TLS
- TFTP
- SFTP
- FXP
- LDAP
- DDNS
- L2TP
- IPSec
- WEBDAV
- HTTP
- HTTPS
- Power Description
- Maximum Power Supply Wattage
- 120 W
- Physical Characteristics
- Height
- 8.9"
- Width
- 9.3"
- Depth
- 6.5"
- Form Factor
- Tower
- Weight (Approximate)
- 5.51 lb
- Miscellaneous
- Package Contents
- TS-632X-4G-US NAS Storage System
- AC Adapter
